KLIPSCH RP-8060FA (BLACK)
Dolby Atmos Floorstanding Speaker
REFERENCE PREMIERE 2018
The Reference Premiere RP-8060FA Dolby Atmos® enabled floorstanding speaker includes a built-in elevation channel speaker integrated into the top of the speaker to reflect sound off the ceiling to deliver the overhead Dolby Atmos® experience in addition to stereo sound towards the listener.
Features:
HYBRID TRACTRIX® HORN TECHNOLOGY
Klipsch proprietary Tractrix® horn loading technology ensures high-frequency energy of the RP-8060FA is aimed directly at the listener and reduces unwanted, artificial reverb - meaning you experience the most clear, detailed, lifelike sound possible.
HORN ANATOMY
Klipsch Reference Premiere series speakers feature a compressed molded silicon face thats matted to the 90x90 Tractrix horn to reduces horn resonance for a smoother frequency response. Klipsch computer modeled phase plugs acts as a mechanical filter to further ensure a smooth, flat frequency response while protecting the tweeter from damage.
ALL-NEW Vented Tweeter
A vented tweeter design reduces standing waves behind the tweeter diaphragm for a smoother high frequency reproduction.
The titanium tweeter diaphragm's light weight yet rigid composition exceeds the performance of aluminum, polymer or silk tweeters.
Klipsch award-winning Linear Travel Suspension technology leverages a piston motion of the titanium diaphragm that lowers distortion and delivers real-to-life sound.
A ceramic magnet housing provides premium performance, Klipsch Reference Premiere tweeters set the standard in acoustic reproduction.
CERAMETALLIC™ WOOFERS
Klipsch Proprietary Cerametallic™ woofers are the RP-8060FA signature statement for both sound and aesthetics. This extremely light, rigid materials holds its shape while being able to deliver lower frequencies with maximum efficiency.
WOOFER ANATOMY
Klipsch Cerametallic™ cones are matted to a dual-layer, copper-wound voice coil for exceptional conductivity.
Reference Premiere woofers are housed in a non-resonating, stamped-steel basket that’s secured to a large magnet motor for exceptional efficiency and low distortion, and matched to our horn-loaded tweeters for optimal acoustic execution.
REAR TRACTRIX® PORT
The rear Tractrix ports of the RP-8060FA floorstanding speaker are perfectly matched to the cabinets and woofers, creating ideal airflow with minimal distortion or turbulence even at the lowest frequencies.
FINISHED TO PERFECTION
The RP-8060FA ebony and walnut finishes boast satin painted baffles with a scratch resistant design for an elegant audio solution to your home theater system.
MAIN CHANNEL | |
FREQUENCY RESPONSE
|
32-25kHz +/- 3dB
|
SENSITIVITY
|
98dB @ 2.83V / 1m
|
POWER HANDLING (CONT/PEAK)
|
150W / 600W
|
NOMINAL IMPEDANCE
|
8 Ohms Compatible
|
CROSSOVER FREQUENCY
|
1750Hz
|
HIGH FREQUENCY DRIVER
|
1” Titanium LTS Vented Tweeter with Hybrid Cross-Section Tractrix® Horn
|
LOW FREQUENCY DRIVER
|
Dual 8” Cerametallic Cone Woofers
|
ENCLOSURE MATERIAL
|
MDF
|
ENCLOSURE TYPE | Bass-Reflex via rear-firing Tractrix® ports |
INPUTS
|
Dual Binding Posts
|
HEIGHT
|
43.12” (109.5 cm)
|
WIDTH
|
10.90” (27.7 cm)
|
DEPTH
|
19.80” (50.3 cm)
|
WEIGHT
|
71 lb (32.2 kg)
|
HEIGHT CHANNEL | |
FREQUENCY RESPONSE | Conforms to Dolby Atmos Specifications |
SENSITIVITY | Conforms to Dolby Atmos Specifications |
POWER HANDLING | 75W/300W |
CROSSOVER FREQUENCY | 2kHz |
NOMINAL IMPEDANCE | 8 ohms Compatible |
HIGH FREQUENCY DRIVER | 1” Titanium LTS Tweeter with Hybrid Tractrix Horn |
LOW FREQUENCY DRIVER | 6.5” Cerametallic Cone Woofer |
ENCLOSURE TYPE | Acoustic Suspension |
INPUTS | Single Gold Plated Binding Posts |
